All segments, including the fuel icon, will flash.
When the last segment clears, a low fuel warning is activated. The segments of the fuel gauge show the level of fuel in the fuel tank. The functions and features of the rider information center are shown in the diagram and table below. The information center is set to display standard units of measurement and a 12-hour clock at the factory. If this occurs, your Polaris Dealer can provide a proper diagnosis. If the instrument cluster fails to illuminate, a battery over-voltage may have occurred, and the instrument cluster may have shut off to protect the electronic speedometer. All segments will light up for one second at start-up. The rider information center is located in the instrument cluster. The override button will not function as a mode button if the transmission is in reverse. Use this button to toggle through the mode options available.įor ATVs that don't have a mode button on the cluster, the reverse override switch on the left handlebar (pictured below) acts as the mode button when held down for approximately one half-second.
The mode button (1) is located near or on the instrument cluster. Do not operate the vehicle if this warning appears. Vehicle speed will be limited to 15 mph (24 km/h) if the seat belt is not secured.Īppears if an Electronic Fuel Injection (EFI) related fault occurs. The driver's seat belt is equipped with a seat belt interlock. Illuminates when the headlamp switch is set to high beam.Ī reminder to the operator to ensure all riders are wearing helmets and seat belts before operating. Illuminates when the transmission is in neutral and the ignition key is in the ON position. If the light remains on, the EPS system is inoperative. Illuminates briefly when the key is turned to the ON position. If the indicator flashes, the overheating condition remains, and the system automatically will reduce engine power.Įlectric Power Steering (EPS) Warning (if equipped) Illuminates to indicate an overheated engine. When metric mode is selected, speed displays in kilometers per hour. When standard mode is selected, speed displays in miles per hour. These instrument clusters include a speedometer (1), indicator lamps (2), mode button (3) and rider information center (4). Some features will vary from model to model. Hardware only - $295.Some Polaris ATV, ACE, RANGER and RZR models are equipped with analog instrument clusters that include a 2-inch LCD digital display.Tier 3 Dealer: (Less than $2,500 in purchases)
